Creality Falcon 2 (22W / 40W) Laser Crosshairs Brackets
Choose options
ATTENTION: If you are located in the United States - this product is fine to ship as it contains only the mounting brackets and hardware for the laser crosshairs module. It does not contain the laser module itself. This is why the price is less expensive than the full kit. A link to the laser module can be found below, scroll down to the "What is included" section.
Upgrade your Creality Falcon 2 (22W/40W) laser cutter and engraver with the parts as seen in the video below. THIS LISTING FITS BOTH 22W and 40W MODELS. IT WILL FIT BOTH MODELS WITH OR WITHOUT THE FUME EXTRACTORS. IF YOU HAVE THE PRO MODEL WITH THE ENCLOSURE, PLEASE USE THE CONTACT LINK FOR A CUSTOM SOLUTION.
A laser crosshairs module is a tool designed to assist operators in aligning their workpieces efficiently and accurately. It projects a crosshair pattern onto the surface of the material, providing a visual guide for precise positioning. This feature dramatically simplifies the setup process, ensuring that your designs are flawlessly aligned before starting the engraving process.
Unfortunately the Creality Falcon 2 laser cutters and engravers do not come equipped with a laser crosshairs module making the alignment and positioning process quite cumbersome. Take the guesswork away with this upgrade!
In addition to the video I have also provided a written guide here:
https://embracemaking.com/blogs/resources/creality-falcon-22w-40w-laser-crosshairs-guide
What is included:
Laser Crosshair Module with Integrated Switch- Mounting Brackets
- All Hardware
Note here is a compatible laser module you can use if you are located in the United States:
You will have to get a USB A to USB C connector if you want to plug it into the Falcon laser module directly, or you can route the cable along the gantry and power the crosshairs externally.
Other Notes:
Nominal offsets for normal planar (flat) position:
22W Module: X: -55mm Y: -43mm
40W Module: X: -60.5mm Y: -35mm
Nominal offsets for rotary position:
22W Module: X: -55mm Y: 0mm
40W Module: X: -60.5mm Y: 0mm
DANGER: The laser crosshairs module is a 5mW Class IIIa red laser. Class IIIa lasers are continuous wave, intermediate power (1-5 mW) devices. Some examples of Class IIIa laser uses are laser pointers and laser scanners. Direct viewing of the Class IIIa laser beam could be hazardous to the eyes. Do not view the Class IIIa laser beam directly. Do not point a Class IIIa laser beam into another persons eyes.
