The Embrace Making 'Universal Top Mount Spool Stand' is sold as a universal kit with all of the core components for the spool stand itself. It also includes the necessary hardware (nuts, bolts, screws) to adapt to a multitude of printers. This accessory hardware packet will have the necessary screws for the various machine applications. You can find the official supported list of printers below.
The Universal Top Mount Spool Stand can be found at the link below.
► https://embracemaking.com/products/universal-top-mount-spool-stand
The following picture shows the dimensions with a typical 1kg spool installed. (right click and open in new tab for a larger view).
The following picture depicts the assembly of the Universal Top Mount Spool Stand. (right click and open in new tab for a larger view).
To keep packaging and logistics simple and affordable, the 3D printed accessory for adaptation for your specific machine will be printed by you. The links to the STL files can be found below along with installation instructions for the various machines.
OFFICIAL SUPPORTED APPLICATIONS
(being updated and expanded)
****************************************************************************************
Creality Ender 3 (All Models Including Clones) Runout Sensor Bracket:
► https://makerworld.com/en/models/428902
Ender 3 V3 (Core XZ). QTY: 2 M3 x 10 Socket Head Screws at rear of the top frame member. See video below for install walkthrough (starts at spool stand timestamp).
Also fits Ender 3 V3 SE/KE using the original M5x10 Button Head Cap Screws in the original spool mount location at the top of the frame. (starts at SE/KE timestamp). You will need the 6mm riser feet found here:
► https://makerworld.com/en/models/468475
Also fits traditional Ender 3 models (with V slot extrusion top frame). Therefore it should also work with Ender 3 clones using V slot extrusion top frame member. Use the included QTY:2 M3 T-Nuts + QTY:2 M3 x 10 Socket Head Cap Screws in the top slot of the V slot profile. (video starts at relevant timestamp)
You will need the 3mm riser feet found here:
► https://makerworld.com/en/models/468475
****************************************************************************************
Creality K1 / K1 MAX PTFE Tube Guide Adapter
The Creality K1 and K1C have the runout detection sensor mounted at the back of the machine frame. It can be enhanced with the runout sensor alignment guide and you will need the PTFE tube clip found at the link below. (video below is timestamped at the relevant location).
► https://makerworld.com/en/models/468487
For the K1 MAX application you will need to extend the height of the spool stand using the 25mm splice extension found below:
► https://makerworld.com/en/models/467455
****************************************************************************************
Creality Ender 3 V3 PLUS Runout Sensor Bracket and 50mm Extension
► https://makerworld.com/en/models/499405#profileId-415093
Ender 3 V3 PLUS (Core XZ). QTY: 2 M3 x 10 Socket Head Screws at rear of the top frame member. See video below for install walkthrough (starts at spool stand timestamp). This video shows the standard size V3 but the process is identical on the V3 PLUS.
****************************************************************************************
SOVOL SV06 / SV06 ACE / SV06 PLUS / SV07
SV06 / SV06 ACE: No additional prints or parts necessary. Simply install the spool stand beside the machine and use the existing runout sensor at the top of the machine to route the filament down into the extruder.
SV06 Plus / SV07: These are taller machines. Use the 50mm splice extension found at the link below to extend the height of your spool stand to accommodate:
