In the following video we explore the capabilities of the Creality Raptor Pro 3D scanner with the 3D Scan Bridge accessory
After searching the web I have not found a good comprehensive comparison table showing the different key technical details of the various Creality 3D scanners. So I put one together for you below. The scanners are organized from left to right from least expensive to most expensive.
If you're looking for a 3D Scanner, you can find the scanners featured in this comparison using my affiliate links. Using the links will cost you NOTHING extra but will help support my work:
✅ Creality Raptor Pro (Best All Round!)
✅ Creality Raptor X (Ultimate!)
✅ Creality Sermoon S1 (Newest!)
✅ Creality Otter (Budget)
✅ 3D Scan Bridge
✅ Need a 3D Printer to bring your scan creations to life? Check out the Creality K2 PLUS
How do these scanners line up?
| Feature | CR-Scan Otter | Raptor Pro | Sermoon S1 | RaptorX |
|---|---|---|---|---|
| Price (USD) | $699 | $1,699 | $2,699 | $3,599 |
| Accuracy | Up to 0.02 mm | Up to 0.02 mm | Up to 0.02 mm | Up to 0.02 mm |
| Volumetric Accuracy | Not specified | 0.02 mm + 0.08 mm/m | 0.02 mm + 0.08 mm/m | 0.02 mm + 0.06 mm/m |
| Scanning Speed (FPS) | Up to 20 fps | Up to 60 fps (laser), 30 fps (NIR) | Up to 90 fps (single laser lines), 30 fps (cross lines) | Up to 60 fps (laser), 30 fps (NIR) |
| Scanning Rate (Points/s) | Not specified | 420,000 to 660,000 measurements/s, 3,580,000 measurements/s for NIR | 108,000 - 1,428,000 measurements/s blue laser, 4,600,000 measurements/s for NIR | 420,000 - 1,020,000 measurements/s blue laser, 3,580,000 measurements/s for NIR |
| Technology / Light Source | Four-lens stereo vision with NIR structured light | 22 cross + 7 parallel blue laser lines, NIR structured light | Blue laser lines (1, 7 parallel, 34 cross, with NIR structured | 34 cross, 7 parallel blue laser lines, NIR structured |
| Working Distance | 110-1000 mm | 160mm - 400mm (Blue Laser), 170mm - 1000mm (NIR) | 150mm - 600mm (Blue Laser), 170mm - 1200mm (NIR) | 160mm - 400mm (Blue Laser), 170mm - 1000mm (NIR) |
| Object Size Range | 10-2000 mm | 5mm to 4000 mm | 5mm to 4000mm | 5mm to 4000 mm |
| Dimensions | 165 x 37 x 59 mm | 193.7 x 119.8 x 81.7 mm | 225 x 53 x 76 mm | 193.7 x 119.8 x 81.7 mm |
| Weight | 390g | 405 g | 508 g | 405 g |
| Wireless Support | Wi-Fi 6 With Scan Bridge | Wi-Fi 6 With Scan Bridge | Wi-Fi 6 With Scan Bridge | Wi-Fi 6 With Scan Bridge |
| Other Features | 24-bit full-color scanning, anti-shaking, scans black/metal without spraying | High-speed dual-mode, full-color, anti-shake, metrology-grade, full color scanning | Metrology-grade precision, full-color, spray free for black metal objects, AI powered software | High-speed dual-mode, full-color, anti-shake, metrology-grade, full color scanning |
